Binary Trees in Python

Binary Tree

Binary Tree is a form of a tree whose nodes cannot have more than two children. Each node of the binary tree has two pointers associated with it, one points to the left child, and the other points to the right child of the node. It is an unordered tree having no fixed organized structure for the arrangement of nodes.

Note: Binary Tree is slow for the searching, insertion, or deletion of the data because of its unordered structure. The time complexity of these operations is $O(N)$ .

Binary Search Tree

Binary Search Tree(BST) is a type of binary tree which is in ordered form. It has a fixed organized structure for the arrangement of nodes. The structure follows the following rules:

Left child of the node must have a value less than its parent’s value
Right child of the node must have a value greater than its parent’s value

Note: BST is faster than a binary tree in the searching, insertion, or deletion of the data because of its ordered structure. The time complexity of these operations is $O(log N)$ .

# Creating node class
class Node:
    def __init__(self, data):
        self.data = data
        self.leftChild = None
        self.rightChild = None
# Function to insert in BST
    def insert(self, data):
        # if value is lesser than the value of the parent node
        if data < self.data:
            if self.leftChild:
                # if we still need to move towards the left subtree
                self.leftChild.insert(data)
            else:
                self.leftChild = Node(data)
                return
        # if value is greater than the value of the parent node
        else:
            if self.rightChild:
                # if we still need to move towards the right subtree
                self.rightChild.insert(data)
            else:
                self.rightChild = Node(data)
                return
    # function to print a BST
    def PrintTree(self):
        if self.leftChild:
            self.leftChild.PrintTree()
        print( self.data),
        if self.rightChild:
            self.rightChild.PrintTree()
# Creating root node
root = Node(27)
# Inserting values in BST
root.insert(14)
root.insert(35)
root.insert(31)
root.insert(10)
root.insert(19)
# printing BST
root.PrintTree()

Insertion in BST

# Creating node class
class Node:
    def __init__(self, data):
        self.data = data
        self.leftChild = None
        self.rightChild = None
# Function to insert in BST
    def insert(self, data):
        # if value is lesser than the value of the parent node
        if data < self.data:
            if self.leftChild:
                # if we still need to move towards the left subtree
                self.leftChild.insert(data)
            else:
                self.leftChild = Node(data)
                return
        # if value is greater than the value of the parent node
        else:
            if self.rightChild:
                # if we still need to move towards the right subtree
                self.rightChild.insert(data)
            else:
                self.rightChild = Node(data)
                return
# Function to search in BST
    def search(self, val):
        # if value to be searched is found
        if val==self.data:
            return str(val)+" is found in the BST"
        # if value is lesser than the value of the parent node
        elif val < self.data:
            # if we still need to move towards the left subtree
            if self.leftChild:
                return self.leftChild.search(val)
            else:
                return str(val)+" is not found in the BST"
        # if value is greater than the value of the parent node
        else:
            # if we still need to move towards the right subtree
            if self.rightChild:
                return self.rightChild.search(val)
            else:
                return str(val)+" is not found in the BST"


    # function to print a BST
    def PrintTree(self):
        if self.leftChild:
            self.leftChild.PrintTree()
        print( self.data),
        if self.rightChild:
            self.rightChild.PrintTree()
# Creating root node
root = Node(27)
# Inserting values in BST
root.insert(14)
root.insert(35)
root.insert(31)
root.insert(10)
root.insert(19)
# searching the values
print(root.search(7))
print(root.search(14))

Searching in BST
