Hands-on AWK

For many of us, our first exposure to a programming language is a general-purpose programming language like C, Python, or Java. AWK, on the other hand, was designed with a very targeted goal of being able to process text-based data without having to write several lines of code. That’s not to say that AWK is limited to performing this function alone—far from it. However, effectiveness of AWK is largely due to the control it offers over writing these quick one-liner command-line programs, as well as short scripts to serve an immediate need. Imagine having the prowess to manipulate system logs, configuration files and spreadsheet data from the command line in just a few keystrokes. Another reason why it’s worthwhile learning AWK is because it comes pre-installed as the utility awk on Unix-like operating systems, and its inclusion into the Unix ecosystem makes it very convenient to use.

The letters A, W, and K in AWK stand for the last names of the individuals (Alfred Aho, Caspar Weinberger, and Brian Kernighan) who designed the programming language in the late 1970s.

Note: This blog assumes a passing familiarity using a command-line shell (cat, echo, pipe, and redirection), some prior programming exposure (concepts like comparison and logical operators, expressions, conditionals, and loops).

The coding environments included in this blog make use of an input text file, that can be viewed in each coding environment. For convenience, we show the file here in a tabular format:

Note: The input file may not necessarily have the same number of fields on each line.

An unusual workflow #

The manner in which an AWK program runs is unusual because when it’s run, the code is repeatedly executed for each record in the input — behind the scenes.

Whenever a record is read, there are special built-in variables $1, $2, $3 (and so on) that can be used for accessing the values in the first, second, third (and so on) fields of that record. The entire record can also be retrieved all at once using the built-in variable $0.

An AWK program#

A basic AWK program consists of one or more pattern-action pairs in the following general form.

pattern { action }

• The pattern is an expression that evaluates to a value that’s regarded as true or false.

  Note: AWK does not have a boolean data type, but 0 and the empty string "" are regarded as false, and all other values as true.

• The action consists of one or more statements. In case there are multiple statements within an action, they may be separated by either a semicolon character (;) or a newline.

When running an AWK program, each pattern is tested against every record of the input stream, one by one. Whenever the pattern evaluates to true, the corresponding action is executed.

The entire program is enclosed within single quotes, and can be run from the command line using the awk utility:

awk 'pattern { action }' inputfile

Here, inputfile is the input to the program. More than one file can also be passed as input.

awk 'pattern { action }' file1 file2

Since we are running the program using the awk utility in the shell, output can be stored in a file using the redirection operator >.

awk 'pattern { action }' inputfile > outputfile

In the same vein, the input can also be taken using the pipe operator.

cat inputfile | awk 'pattern { action }'

Examples#

1. In the following one-liner, we print the records for which the age (in the third column) is less than $30$.

2. See how none of the records get printed when 0 or the empty string "" is used as a pattern.

3. The pattern in the following snippet is a non-empty string (from the second column in inputfile) which is considered true. So the action is executed for all records. Observe, also, how we can concatenate different strings by placing them side by side.

Patterns and actions are optional#

It isn’t necessary to specify both pattern and { action }. Just one of them suffices:

• When pattern is not specified, the action is performed for all the records.

• When { action } is not specified, the default action is to print all the matched records.

The BEGIN and END patterns#

There are other ways to specify a pattern than creating expressions using numbers, strings, arithmetic or logical operators

Think about how to add the scores listed in the fifth column of the input file.

Regular expressions as patterns#

Regular expressions (regex) are symbolic ways to represent a pattern, and specify what the matching text should look like.

The syntax of regular expressions used in AWK is known as the Extended Regular Expression (ERE).

This syntax is also used by many other languages and unix-based utilities. So it’s super useful to know.

Instead of searching the entire record for a match against a regex, we can use the operator ~ to check if a regular expression matches a smaller portion of the given text. Similarly, the operator !~ is useful for checking if there is no match.

Usage: The regular expression must appear on the right of ~ or !~, and the text being searched must go on the left.

Regex metacharacters#

A regular expression may include some special characters called metacharacters, so called because they are not matched with a text in a literal sense. Instead they are interpreted as a rule for matching text. Here are some examples:

• The metacharacters [ and ] match one of (possibly) many characters that appear enclosed within the brackets. For example, [AbC] means a single character: either A, b, or C. Expressions like these are called character classes.
• A range of characters can also be represented as character classes. For example:
  • [0-9] means a single numeric character from $0$ to $9$.
  • [a-zA-Z] means a single alphabetical character in upper or lower case.
• The metacharacters [^ ] specify a single character other than the ones appearing after the symbol ^ inside the character class . For example, [^bcd] means any character other than b, c, or d.

The metacharacters $ and ^ (outside a character class) take on meaning relative to some other character X in the following way:

• ^X means lines that start with X.
• X$ means lines that end with X.

• The metacharacter . means any single character.
• The metacharacter | means characters specified by the regex on its left or its right. For example, ab|[cd] matches either ab, c or d.
• The metacharacters () are used for grouping characters. For example, ^M versus ^(Me) mean two different things (lines beginning with M versus lines beginning with Me).

Note: The GNU implementation of AWK, known as GAWK, also supports additional features inluding the use of metacharacters () for capturing portions of matched text for later use.

The metacharacters *, +, ?, {m,n} are called quantifiers. They also take on meaning relative to their preceding character, say X:

• The expression X* means zero or more occurrences of X.
• The expression X+ means one or more occurrences of X.
• The expression X? means zero or one occurrence of X.
• The expression X{n,m} means at least n and at most m occurrences of X. (This is not supported in the editor below.)

Note: To match a metacharacter literally, we need to use the escape character \. For example /\*/ to match the character *.

Data structure: Associative array#

An associative array is the only data structure supported by AWK. It essentially consists of index and value pairs, where the index can be used for retrieving the corresponding value.

An associative array is created simply through an assignment statement that maps a value to an index. The syntax looks like this:

arr["ind"] = "val"

We can also add more elements to an array using assignment statements like the one above.

Notice how we loop over the array arr using a for(i in arr) style loop. In each round, i is set to the index of an element in arr (and not an element in arr).

AWK also supports a C-style for loop (see exact syntax below), but it isn’t suitable for traversing over an associative array because the keys of an associative array may not fall in the required range of numbers.

for(i = 1; i < 10; i++)

Here’s another example where the number of individuals in each team count is computed.

Built-in variables and functions#

Other than $0, and $1, $2, $3 etc., there are other built-in variables that are easy to remember and easy to use. Some of these are shown in the following table:

AWK supports many predefined mathematical functions (like log, sqrt, exp, sin) as well as functions for working with strings (such as substr, length, toupper ).

Let’s see a few more examples before we call it a day.

Example 1: Overriding default values#

We can use any character as a field separator in the output by changing the default value of the variable OFS. The default values for OFS can be overridden as shown below.

Also note how, in the following example, we print the record number for each row using the variable NR (for number of records).

Example 2: Accessing fields using rvalues#

If a variable varname is assigned an integer $k$, then the syntax $varname can be used for accessing the fields in the $k^{th}$ column.

For example, since NF stores the number of fields in the current record, we can access the last field in that row using the syntax $NF.

Example 3: Formatting output#

The C style printf is used for showing the output formatted in a tabular form. The argument %-20s sets the width of the padded string at $20$ characters and aligns it to the right.

The next two examples use built-in functions.

Example 4: Splitting a string#

The built-in function split(str, arr, ch) is used, which splits the string str around the character ch and stores the resulting substrings in the array arr. We use this function below to extract the month and year from each individual’s joining date.

Example 5: Find and replace#

Example 6: Bigger programs#

In AWK programs, we can use many constructs similar to the ones available in other languages like if, else, while, switch, and more. One can also define a function in an AWK program, and then call it from within the scope of an action.

A final word#

It’s worth noting that AWK is a Turing complete language, which means that it can be utilized for implementing any algorithm. That being said, some AWK examples of its use include tasks like data filtration and manipulation.

This blog is far from being a complete tutorial, but we hope that it is effective in removing any entry level barriers for a faster and a happier learning experience.
