How to plot a histogram in Python using Matplotlib
Histograms are essential tools in data analysis and visualization. They provide a graphical representation of the distribution of a dataset, helping analysts understand the underlying patterns and characteristics of the data. A histogram divides the data into intervals called bins and displays the frequency of data points falling into each bin as bars.
Understanding how to plot histograms in Python using Matplotlib is crucial for software developers and data professionals. It equips individuals with the skills to visualize and analyze data effectively, a fundamental aspect of many software development and data science tasks. Whether you’re building machine learning models, designing data-driven applications, or simply exploring datasets for insights, the ability to create informative histograms can significantly enhance your capabilities.
Matplotlib, a popular Python library for data visualization, offers a straightforward way to create histograms. You can customize various aspects of the histogram, such as the number of bins, colors, and labels, to effectively communicate insights from your data.
In this blog, we’ll explore how to plot histograms in Python using Matplotlib, covering the syntax, parameters, and implementation details.
Features of the histogram plot#
Histograms offer several features that make them valuable for data analysis:
Distribution visualization
Bin customization
Data comparison
Insight generation
Distribution visualization#
Histograms visually represent the data distribution, making identifying patterns, trends, and outliers easier. The following are some important distributions:
Normal distribution: A bell-shaped symmetric distribution where most data cluster around the mean, with fewer data points in the tails. In a histogram, a normal distribution appears as a symmetrical mound centered around the mean.
Uniform distribution: A distribution where all outcomes are equally likely. In a histogram, a uniform distribution appears as a flat line, indicating that all values occur with equal frequency.
Poisson distribution: A discrete probability distribution that represents the number of events occurring in a fixed interval of time or space, given a constant mean rate of occurrence. A Poisson distribution appears discrete in a histogram, with a peak around the mean value and tails extending toward zero and infinity.
Exponential distribution: A distribution that represents the time between events in a Poisson process. Events occur continuously and independently at a constant average rate. In a histogram, an exponential distribution appears skewed with a long tail on the right side.
Left-skewed distribution: This is also known as a negatively skewed distribution, where the tail of the distribution extends to the left, indicating more extreme low values. A left-skewed distribution appears in a histogram with a longer tail on the left side.
Right-skewed distribution: Also known as a positively skewed distribution, this type of distribution has a tail that extends to the right, indicating more extreme high values. It appears in a histogram with a longer tail on the right side.
Bimodal distribution: A distribution with two distinct peaks, indicating two separate modes or clusters of data. A bimodal distribution appears in a histogram with two distinct peaks separated by valleys.
Log-normal distribution: A distribution where the logarithm of the data follows a normal distribution. In a histogram, a log-normal distribution appears skewed with a long tail on the right side after transforming the x-axis to a logarithmic scale.
Some examples of these distributions are as follows:
Bin customization #
Users can customize the number and size of bins to control the granularity of the histogram, allowing for better data exploration.
The bin customization in histograms is illustrated below. Each histogram represents the same dataset but with different numbers of bins: 10, 20, 30, 40, 50, and 60 bins:
Data comparison #
Histograms enable the comparison of different datasets or subsets of data, facilitating the identification of similarities and differences.
Below is an image that compares two schools’ exam scores using histograms. The x-axis represents exam scores, while the y-axis represents the number of students. This visualization allows for a direct comparison between the performance of students from each school, highlighting any disparities or similarities in their scores:
Insight generation #
Examining the histogram’s shape, central tendency, spread, and skewness can help analysts gain insights into the data’s underlying characteristics.
Let’s analyze a histogram concerning these parameters to gain deeper insights:
Shape: The histogram’s shape can reveal the data’s distribution pattern. For example, a symmetrical shape suggests a normal distribution, indicating that the data is evenly distributed around the mean. A skewed shape, whether left or right, suggests an imbalance in the distribution, with more data points clustered toward one end of the range. This insight allows analysts to understand the general trend and variability within the dataset.
Central tendency: The central tendency, represented by measures such as the mean, median, or mode, provides insight into the typical or central value around which the data is clustered. Examining the central tendency in the histogram helps analysts identify the dataset’s most common or typical outcome, providing a reference point for further analysis and decision-making.
Spread: The spread of the data, also known as dispersion, describes the extent to which the data points are scattered or clustered. A wider spread indicates greater variability within the dataset, while a narrower spread suggests less variability and a more consistent pattern. Understanding the spread in the histogram allows analysts to assess the range of possible values and the degree of uncertainty associated with the data.
Skewness: Skewness measures the asymmetry of the distribution. A positively skewed distribution has a longer right tail, indicating more extreme values on the higher end of the range. Conversely, a negatively skewed distribution has a longer left tail, indicating more extreme values on the lower end of the range. Analyzing skewness in the histogram provides insights into the direction and extent of the skew, helping analysts understand the distribution’s shape and potential outliers.
Syntax#
The syntax for creating a histogram using Matplotlib is straightforward:
import matplotlib.pyplot as plt# Datadata = [...] # Input your dataset here# Plotting the histogramplt.hist(data, bins=..., color='...', edgecolor='...', alpha=..., ...)# Adding labels and titleplt.xlabel('X-axis Label')plt.ylabel('Y-axis Label')plt.title('Title of Histogram')# Displaying the plotplt.show()
This syntax outlines the essential steps for creating a histogram using Matplotlib. You’ll need to replace [...] with your dataset, specify the number of bins with bins=..., choose a color for the bars with color='...', set the edge color of the bars with edgecolor='...', and adjust the transparency of the bars with alpha=..., among other parameters as needed. Finally, don’t forget to add appropriate labels to the x-axis and y-axis and provide a title for the histogram.
Parameters#
The plt.hist() function accepts several parameters that control the appearance and behavior of the histogram:
x: The input data is to be plotted as a histogram. This can be a list, a Numpy array, or any other sequence-like object, such as a pandas Series.bins: This parameter controls the number of bins used in the histogram. It can be an integer specifying the number of bins or a sequence of bin edges defining the bin boundaries. If not specified, a default of 10 bins will be used.range: This parameter sets the range of values to be displayed on the x-axis. It can be a tuple specifying the minimum and maximum values for the bins. If not specified, the range is automatically determined from the input data.density: This is a boolean parameter that, if set toTrue, normalizes the histogram such that the area under the histogram equals 1, converting the counts to a probability density. The default isFalse.weights: This array-like parameter assigns weights to each data point. This can be used to specify the importance of individual data points in the histogram.cumulative: This is a boolean parameter that plots a cumulative histogram if set toTrue. The default isFalse.histtype: This parameter specifies the type of histogram to be plotted. Options include'bar','barstacked','step','stepfilled'. The default is'bar'.align: This parameter controls the alignment of the bars with the bin edges. Options include'left','mid','right'. The default is'mid'.orientation: This parameter specifies the orientation of the histogram. Options include'vertical'or'horizontal'. The default is'vertical'.color: This is the color or sequence of colors used for the bars in the histogram.label: This is a label for the histogram, which can be used for creating a legend.stacked: This is a boolean parameter that, if set toTrue, stacks multiple histograms on top of each other. The default isFalse.alpha: This is the transparency of the bars in the histogram. It ranges from 0 (transparent) to 1 (opaque).edgecolor: This is the color of the edges of the bars in the histogram.linewidth: This is the width of the edges of the bars in the histogram.
These are the main parameters of the hist() function in Matplotlib. You can adjust these parameters to customize the appearance and behavior of your histogram according to your specific requirements.
Return type#
The hist() function in Matplotlib returns a tuple containing three elements:
n: This is an array or list of counts for each histogram bin. The length of this array corresponds to the number of bins.bins: This is an array or list of bin edges defining the boundaries of each bin in the histogram.patches: This is a list ofPatchobjects representing the histogram bars.
After creation, you can use these returned values to further analyze or manipulate the histogram. For example, you might want to:
Access and modify the counts of each bin (
n): Adjusting the counts can be useful for normalizing the data, applying weights, or transforming the data for comparison with other datasets.Access and modify the bin edges (
bins): Changing the bin edges can help refine the histogram’s granularity or align it with specific data ranges or intervals of interest.Modify the properties of the histogram bars (
patches): Customizing the appearance of the bars, such as their color, transparency, or edge style, can enhance the visualization for better clarity and presentation.
Implementation#
We’ll use the Iris dataset, a popular dataset in machine learning and statistics. It contains measurements of iris flowers’ sepal and petal lengths and widths. For this histogram, we’ll focus on the sepal length.
import matplotlib.pyplot as pltimport seaborn as sns# Load example dataset from seaborndata = sns.load_dataset("iris")# Set up the figureplt.figure(figsize=(8, 6))# Extract a single column for the histogramsepal_length = data["sepal_length"]# Plot the histogramn, bins, patches = plt.hist(sepal_length, bins=10, color='skyblue', edgecolor='black', alpha=0.7)# Add title and labelsplt.title('Histogram of Sepal Length')plt.xlabel('Sepal Length (cm)')plt.ylabel('Frequency')# Add grid linesplt.grid(True)# Show the plotplt.show()
The following is the output of the code above:
Let’s review the code above:
Line 1: We import the
pyplotmodule of Matplotlib and alias it asplt.Line 2: We import the Seaborn library and alias it as
sns. Seaborn provides datasets and functions for statistical data visualization.Line 5: We load the Iris dataset using Seaborn’s
load_dataset()function. This dataset contains information about iris flowers, including sepal and petal measurements.Line 8: We create a new figure with a specified size of 8x6 inches using
plt.figure(). This sets up the canvas for our histogram.Line 11: We extract the
"sepal_length"column from the dataset and assign it to the variablesepal_length.Line 14: We plot the histogram of sepal lengths using
plt.hist(). We specify 10 bins and customize the histogram bars, edges, and transparency color.Line 17: We set the plot title to
Histogram of Sepal Lengthusingplt.title().Line 18: We label the x-axis as
Sepal Length (cm)usingplt.xlabel().Line 19: We label the y-axis as
Frequencyusingplt.ylabel().Line 22: We add grid lines to the plot using
plt.grid(True)to improve readability.Line 25: Finally, we display the histogram plot using
plt.show().
Note: This implementation demonstrates how to plot a histogram in Python using Matplotlib, utilizing a sample dataset from the Seaborn library. Following these steps lets you visualize the data distribution and gain insights into its characteristics.
Conclusion#
Mastering the creation of histograms in Python using Matplotlib opens up a world of possibilities for software developers and data professionals. Histograms serve as powerful tools for understanding the distribution and characteristics of data, enabling informed decision-making and insightful analysis. By delving into the syntax, parameters, and implementation details outlined in this blog, individuals can enhance their data visualization skills and excel in various domains, from software development to data science. Whether you’re visualizing trends in financial data, analyzing customer behavior in e-commerce, or exploring patterns in scientific research, the ability to craft informative histograms empowers you to unlock valuable insights and drive impactful outcomes in your projects and career endeavors.
Next steps #
This blog has provided an in-depth exploration of plotting histograms using Matplotlib, a fundamental data analysis and visualization skill. However, the journey in data science is vast and rich, offering numerous opportunities for further growth and exploration. Here are some potential next steps to continue enhancing your data science skill set:
