Top 30 System Design Interview Questions in 2025

While SDI questions tend to evolve, many have remained popular across the industry. These questions are well-suited to evaluate candidates on two important levels:

• Test the candidate’s understanding of System Design fundamentals.

• Evaluate the candidate’s ability to apply those fundamentals in real-world applications.

Today, we’ll break down the top 30 System Design interview questions for 2025. These are essential questions asked at top companies like Google, Amazon, Meta, and more. Mastering these problems and their solutions will give you a huge leg up in your System Design interview prep.

Finally, I will leave you with a few battle-tested strategies that you can use to confidently take on any System Design question you encounter.

Top 30 System Design interview questions#

I have divided these 30 essential System Design problems into three difficulty levels:

Easy System Design interview questions#

1. Design an API rate limiter for sites like Firebase or GitHub

2. Design a pub/sub system like Kafka

3. Design a URL-shortening service like TinyURL or bit.ly

4. Design a scalable content delivery network (CDN)

5. Design a web crawler

6. Design a distributed cache

7. Design an authentication and SSO platform like Auth0

Before we start breaking down specific questions, I want to give you some high-level System Design tips that will enable you to confidently approach any problem.

Tips for any SDI question#

• Start each problem by stating what you know: List all required features of the system, common problems you expect to encounter with this sort of system, and the traffic you expect the system to handle. The listing process lets the interviewer see your planning skills and correct misunderstandings before you begin the solution.

• Narrate any trade-offs: Every System Design choice matters. At each decision point, list at least one positive and one negative effect of that choice.

• Ask your interviewer to clarify: Most System Design questions are purposefully vague. Ask clarifying questions to show the interviewer how you view the question and your knowledge of the system’s needs. Also, be sure to state your assumptions before diving into the components.

• Know your architectures: Most modern services are built upon a flexible microservice architecture. Unlike the past’s monolithic architectures of tech companies, microservices allow smaller, agile teams to build independently from the larger system. Some older companies will have legacy systems, but microservices can function in parallel to legacy code and help refresh the company’s architecture.

• Discuss emerging technologies: Conclude each question with an overview of how and where the system could benefit from generative AI (GenAI) and machine learning (ML). This will demonstrate that you’re prepared for not only current solutions but also future solutions.

Note: For information on how ML can boost your SDI performance, check out my blog How machine learning gives you an edge in System Design

System Design interview cheat sheet#

Here is the System Design interview cheat sheet:

Now, let’s examine the specifics of the top System Design interview questions, starting with the easy problems.

Easy System Design interview questions#

I provide a problem statement, requirements, and workflow for each question with a high-level design.

1. Design an API rate limiter for sites like Firebase or GitHub#

Problem statement: Design an API rate limiter that caps the number of API calls the service can receive in a given period to avoid an overload.

Requirements#

Follow these requirements for a rate limiter system:

System Design and workflow#

According to the following high-level rate limiter, the client’s requests are passed through an ID builder, which assigns unique IDs to the incoming requests. The ID could be a remote IP address, login ID, or other attributes. The decision maker fetches the throttling rules from the database and decides according to them. It either forwards the requests to application servers via the requests processor or discards them and provides the client an error message (429 Too many requests). If some requests are throttled due to a system overload, the system keeps those requests in a queue to be processed later.

Note: Look at the detailed design of the rate limiter to find the answers to the questions above.

2. Design a pub/sub system like Kafka#

Problem statement: Design a scalable and distributed pub/sub system like Kafka that can handle massive message throughput. It should also ensure reliable message delivery and support various messaging semantics (at most once, at least once, exactly once).

Requirements#

Follow these requirements for the pub/sub design:

System Design and workflow#

The brokers are responsible for storing the messages sent from the producers and allowing the consumers to read them. Similarly, the cluster manager is to keep an eye on the broker’s health and spin up another broker in case one goes down. The consumer’s details include subscription information, retention period, etc. The consumer manager manages the consumers, who manage consumers’ access to messages in the existing topics.

Note: To answer the above technical questions, you can examine the detailed design of pub/sub.

3. Design a URL-shortening service like TinyURL or bit.ly#

Problem statement: Design a scalable and distributed system that shortens long URLs like TinyURL or bit.ly. The system takes a long URL and generates a new, unique short URL. It should also take a shortened URL and return the original full-length URL.

Requirements#

Follow these requirements for the URL-shortening system:

System Design and workflow#

A load balancer is the first intermediary between the clients and the server, ensuring even distribution of incoming requests to maintain availability and reliability. When a new URL-shortening request comes in, the load balancer forwards it to a server where the rate limiter checks if the client is within the allowed request rate.

The server leverages a sequencer to generate a unique numeric ID for the URL requests. This ID is passed to an encoder, which converts it into a more readable alphanumeric string. The original URL and its corresponding shortened version are stored in a database. To enhance performance, recently accessed URLs are kept in a cache, allowing quick retrieval without repeatedly querying the database.

Note: To explore in depth to get the answer to the above questions, check out the detailed chapters on the TinyURL System Design.

4. Design a scalable content delivery network (CDN)#

Problem statement: Design a scalable content delivery network (CDN) system to efficiently distribute and cache content across globally distributed servers, minimizing latency and ensuring reliable end user content delivery.

Requirements#

Follow these requirements for a CDN system:

System Design and workflow#

When a client requests content, a request routing system kicks in to find the address of the nearest or fastest server, ensuring minimal wait time. A load balancer then routes the request to the optimal server. If the requested content is cached on that server, it is immediately delivered to the client. If not, the server fetches the content from the origin server, caches it locally for more such requests, and then serves it to the user.

The CDN system ensures that frequently accessed content remains readily available while less popular content is periodically purged. The system also includes monitoring and analytics to track performance, optimize routing, and ensure high availability and reliability.

Note: Check out the chapter on the design of a content delivery network to help you understand and get answers to the above questions.

5. Design a web crawler#

Problem statement: Design a web crawler that systematically browses the internet to discover and index web pages. The crawler should efficiently navigate websites, retrieve content, and follow links to discover new pages.

Requirements#

Follow these requirements for the web crawler system:

System Design and workflow#

A web crawler begins by assigning a worker to a URL. Once the DNS is resolved, the worker sends the URL and IP address to an HTML fetcher to establish the connection. The URL and HTML content are extracted from the page and stored in the cache for processing. The duplicate eliminator service then tests this content to ensure no duplicate content is transferred to blob storage. Once this cycle is complete for a single URL, it moves on to the next address in the queue.

Note: To get the answers to the above questions, check out the detailed chapters on the web crawler System Design.

6. Design a distributed cache#

Problem statement: Design a distributed caching system that provides fast, scalable, and reliable data retrieval across multiple servers. The system should efficiently manage cache consistency, handle high volumes of read and write requests, ensure data availability, and provide mechanisms for cache eviction and expiration.

Requirements#

Follow these requirements for the distributed cache system:

System Design and workflow#

A distributed caching system begins by partitioning the data across multiple cache nodes to balance the load and improve access speed. When a client requests data, an application server determines the appropriate cache node based on a consistent hashing algorithm, ensuring an even distribution of requests and quick lookups.

If the data is found in the cache (a cache hit), it is returned to the client immediately, significantly reducing latency. If the data is not found (a cache miss), the system retrieves it from the primary data store, caches it, and then serves it to the client. Cache eviction policies, such as least recently used (LRU) or time-to-live (TTL), manage the removal of stale data to free up space.

Note: To answer such conceptual questions, check out the detailed design of the distributed cache.

7. Design an authentication and SSO platform like Auth0#

Problem statement: Design a secure, scalable, multi-tenant authentication platform that provides identity and access management as a service, similar to Auth0. The system must support user registration, multiple authentication methods, and seamless single sign-on (SSO) across various client applications.

Requirements#

Follow these requirements for the authentication and SSO platform:

System Design and workflow#

When users want to log in, their request is routed through a load balancer and then sent to an authentication server. The system checks whether the user is signing in with a regular email and password or using a third-party login provider. If it’s a third-party login, the system redirects the user to the external provider for verification. Once the login is successful, the authentication service creates a secure token and returns it to the client.

This token acts like a digital badge and is used to identify the user on future requests. It can also be used across multiple applications owned by the same company, enabling single sign-on (SSO). Each token has a built-in expiration time, ensuring that user sessions do not remain active indefinitely.

The authentication system includes important safeguards, such as limiting failed login attempts, detecting suspicious activity, and securely encrypting all stored passwords. It also supports multi-tenancy, meaning user data is kept separate for each business using the platform, so each company only sees its users.

Note: The lesson on authentication and authorization explores the core concepts behind this system, including tokens, login protocols, and user permissions.

Medium System Design interview questions#

I provide each medium system design question’s problem statement, requirements, workflow, and system architecture.

8. Design a video-first social platform like TikTok#

Problem statement: Design a video-first social platform where users can create, upload, watch, and interact with short-form videos (reels). The system should support millions of users, deliver low-latency content, and personalize each user’s video feed based on engagement history.

Requirements#

Follow these requirements for a video-first social platform:

System Design and workflow#

When users open the app, their request is routed to the feed generation service through a load balancer. This service works with a recommendation service to generate a personalized list of videos based on the user’s watch history, likes, and other interactions.

Once the feed is generated, the app streams video content directly from a content delivery network (CDN) to ensure fast loading times, especially for users in different parts of the world. The videos are stored in a media storage system and processed by a video processing service, which handles compression, format conversion, thumbnail generation, and basic moderation.

When a user uploads a video, it’s routed to the video processing service. After processing, the video is saved to media storage, which can become part of the personalized list for users via the recommendation service.

The following high-level design represents a simple workflow of a video-first social platform like TikTok:

Note: The chapter on the content delivery network explores how content is delivered quickly and efficiently to users worldwide.

9. Design an AI-powered customer support platform#

Problem statement: Design a scalable customer support platform for a large e-commerce business. The system should use a collection of specialized AI agents to automatically understand, route, and resolve customer queries in real time. If the issue isn’t resolved automatically, the system should escalate it to a human agent with full context preserved.

Requirements#

Follow these requirements for the AI-powered customer support platform:

System Design and workflow#

When a customer submits a query, it is first received by a query router. This component classifies the query type, such as billing, FAQ, or technical issue, based on message content and customer context. The query is then forwarded to the appropriate specialized AI agent.

The FAQ agent retrieves standard responses from the knowledge base to answer common customer questions. For issues related to payments or orders, the billing agent securely accesses account details to provide accurate, account-specific resolutions. Meanwhile, the technical agent helps customers troubleshoot app or product-related problems by walking them through guided solutions.

If the assigned AI agent resolves the query, a response is sent back to the user. If not, the human escalation manager transfers the case to a human support agent with the full interaction history attached. Similarly, a monitoring and logging service records all activity to track performance, generate insights, and help improve future responses, as shown in the following illustration:

10. Design a chat service like Facebook Messenger or WhatsApp#

Problem statement: Design a scalable, reliable, and secure real-time chat service like Facebook Messenger or WhatsApp to support instant messaging, group chats, notifications, and multimedia sharing.

Requirements#

Follow these requirements for the WhatsApp System Design:

System Design and workflow#

In a real-time communication system, senders and receivers are connected to chat servers. Chat servers deliver messages from sender to receiver via a messaging queue. Various protocols, such as WebSocket, XMPP, MQTT, and real-time transport protocol, can be utilized for real-time communication. For this purpose, a manager establishes real-time connections between clients and chat servers; for instance, assume the WebSocket manager establishes WebSocket connections between users and different chat servers. Similarly, the messages can be persistently stored in the database.

Note: Look at the detailed design of the real-time chat service to get answers to such questions.

11. Design a mass social media service like Facebook or Instagram#

Problem statement: Design a social media service used by several million users like Instagram. Users should be able to view a newsfeed with posts by following users and suggesting new content that the user may like.

Requirements#

Follow these requirements for the Instagram system:

Based on the above requirements, let’s create a high-level design of a feed-based social system like Instagram.

System Design and workflow#

The high-level design of a feed-based social network includes posts, timeline generation, feed publishing service, and feed ranking and recommendation engine. The post-service handles the clients’ posts, and the post is published on the client’s wall (page). Similarly, the timeline generation service generates feeds for friends and followers by the timeline generation service. The timeline generation service utilizes the feed ranking and recommendation engine, which ranks and recommends the top N posts to followers based on their interests, searches, and watch history. The generated feed is stored in the database, and the feed publishing service is responsible for publishing and showing the generated feeds to followers. As the feed could contain videos, the CDN is responsible for delivering the videos to followers with low latency.

Note: Look at the detailed design of Instagram for a better understanding.

12. Design a proximity service like Yelp or nearby places/friends#

Problem statement: Design a proximity server that stores and reports the distance to places like restaurants. Users can search nearby places by distance or popularity. The database must store data for hundreds of millions of businesses across the globe.

Requirements#

Follow these requirements for a System Design like Yelp:

System Design and workflow#

The system handles search requests by using load balancers to distribute read requests to the read service, which then queries the quadtree service to identify relevant places within a specified radius. The quadtree service also refines the result before being sent to the clients. For adding places or feedback, write requests are similarly routed through load balancers to the writing service, which updates a relational database and stores images in blob storage. The system also involves segmenting the world map into smaller parts, storing places in a key-value store, and periodically updating these segments to include new places, although this update happens monthly due to the low probability of new additions.

Note:  Look at the detailed design of Yelp to get answers to the above questions.

13. Design a search engine-related service like Typeahead#

Problem statement: Design a typeahead suggestion system that provides real-time, relevant autocomplete and autocorrect suggestions as users type, ensuring low latency and scalability to efficiently handle a large volume of queries.

Requirements#

Follow these requirements for the system:

System Design and workflow#

When a user starts typing a query, each character is sent to an application server. A suggestion service gathers the top N suggestions from a distributed cache, or Redis, and returns the list to the user. An alternate service, the data collector and aggregator, takes the query, analytically ranks it, and stores it in a NoSQL database. The trie builder is a service that takes the aggregated data from the NoSQL database, builds tries, and stores them in the trie database.

Note: Look at the detailed design of the Typeahead system for a better understanding of the system.

14. Design a video streaming service like YouTube or Netflix#

Problem statement: Design a video streaming service like YouTube or Netflix that allows users to upload and stream videos. The service should efficiently store many videos and their metadata and return accurate and quick results for user search queries.

Requirements#

Follow these requirements for a streaming service System Design:

System Design and workflow#

A load balancer first handles video upload requests by sending them to the application servers. The applications server interacts with the video service, which triggers transcoders to convert the video to different formats. These typically range from 140p to 1440p but can reach 4K resolutions. The formatted video is then saved to the blob store, and its metadata is stored on the metadata database. The video service sends the transformed video to CDNs for quick content delivery to end users. Popular and recent uploads are held in a CDN. A content delivery network, or CDN, reduces latency when delivering video to users. The CDN stores and delivers requested data to users in conjunction with colocation sites.

Note: Check out the detailed chapter on YouTube System Design that answers the above concerns during the design.

15. Design a ride sharing service like Uber or Lyft#

Problem statement: Design a system for a ride sharing service similar to Uber, where users can request rides and drivers can accept these requests. The system should efficiently match drivers to riders based on location and availability, handle real-time updates on ride statuses, manage payments securely, and ensure a smooth user experience from booking to completion of the ride.

Requirements#

Follow these requirements for the System Design:

System Design and workflow#

A user’s request is sent to the application server via a load balancer and API gateway. The system accepts the rider’s request, and the trip service or manager provides an estimated time of arrival (ETA) based on different vehicle types. The drivers and location manager use a matching algorithm to find the nearest available drivers and send the request to those drivers by notifying them via a notification service. When a driver matches with a rider, the application should return the trip and rider information. The driver’s location is regularly recorded and communicated to relevant users through a pub/sub service.

Once the ride is complete, the trip manager ensures payment is securely processed through a payment gateway. We leverage a database that stores user and driver profiles, ride history, and payment information. We also use caching mechanisms to speed up access to frequently requested data, and constant monitoring ensures the service runs smoothly.

Note: Check out our guide to designing Uber’s backend for more information on the interview process.

16. Design a recommendation service#

Problem statement: Design a recommendation engine that suggests personalized content or products to users based on their preferences and behavior. The system should efficiently analyze user data, such as past interactions and ratings, to provide accurate and relevant recommendations.

Requirements#

Follow these requirements for a recommendation service:

System Design and workflow#

The recommendation engine’s System Design comprises data collection, processing, and recommendation. When users interact with the application, the data collector service collects data from application servers, such as search, viewing history, ratings, watch times, etc. This data is logged into Kafka for immediate processing.

We use real-time processors to process data and recommend content accordingly. We also use batch processors for periodic offline processing to perform detailed analyses and improve accuracy. Once the data is processed, the ML/AI engine uses different algorithms, such as collaborative filtering, content-based filtering, hybrid approaches, and advanced techniques to recommend personalized suggestions.

17. Design a file sharing service like Google Drive#

Problem statement: Design a scalable, synchronous, cross-platform storage system like Dropbox. Users can store files and photos and access them from other devices.

Requirements#

Follow these requirements for the system:

System Design and workflow#

In a high-level design of a file sharing service like Google Drive, the user’s request to upload or download a file passes through a load balancer to the application servers. The application server sends the upload request to a chunk service for splitting large files into smaller, more easily manageable chunks. These files are then sent to a processing queue that sends and receives requests to store metadata and ensure that files are synchronized between users and accounts. Files are stored in a cloud-based block storage platform, like Amazon S3 (or in-premises blob storage). Users who want to upload or download files contact this storage service through a web server.

Note: To further your learning, explore the detailed design of distributed file systems of tech giants like Google and Facebook (Meta).

18. Design a social network service like Reddit or Quora#

Problem statement: These social network sites operate on a forum-based system that allows users to post questions and links. For simplicity’s sake, focus more on designing Quora. You’ll unlikely need to walk through the design of something like Reddit’s subreddit or karma system in an interview.

Requirements#

Follow these requirements for a System Design like Quora:

System Design and workflow#

In Quora’s high-level design, users interact through a web server, which communicates with an application server to handle actions such as posting questions, answers, and comments. Content like images and videos is stored in blob storage, and question-and-answer data, along with user profiles and interactions, are stored in a MySQL database.

A machine learning engine analyzes user interactions and content to rank answers based on relevance and quality. This engine continuously learns from user feedback to improve its ranking algorithms. For personalized user experiences, a recommendation system utilizes machine learning models to tailor content based on individual interests and behaviors.

Note: Check out the detailed chapter on Quora System Design to help you understand the system.

Hard System Design interview questions#

Hard System Design interview questions refer to complex, open-ended problems that require deep technical knowledge, critical thinking, and the ability to design scalable, efficient systems under constraints. Let’s start with the System Design of a ChatGPT-style service.

19. Design a ChatGPT-style service#

Problem statement: Design a scalable and interactive conversational AI platform, similar to ChatGPT, that allows users to submit prompts and receive real-time, coherent responses from a large language model (LLM). The system should support millions of users, maintain conversation history, and deliver a fast and responsive experience.

Requirements#

Follow these requirements for the ChatGPT-style service:

System Design and workflow#

When a user submits a prompt, the request is initially routed to the API gateway, which verifies authentication and applies rate limiting. The authorized request is then forwarded to the conversation manager. The conversation manager retrieves recent conversations from the user’s chat history, if available, and combines them with the new prompt to create the full input for the LLM. This input is sent to the LLM inference service, which may use distributed replicas or sharded models to manage high traffic.

The LLM inference service generates a response. To improve the user experience, the response is streamed back to the client as it is being generated. This makes the interaction feel fast and natural, especially for longer responses. Once the full response is ready, it is saved to the session store alongside the user’s prompt. All interactions are logged for monitoring and future improvements.

To handle peak traffic smoothly, a queue can be introduced before the inference step to buffer requests. Optionally, depending on the use case, the system may include user profile data for personalization, such as adapting tone, language, or preferred length of answers.

The following illustrations show a high-level design of a ChatGPT-style service:

To answer more such interesting and thought-provoking questions, you can check out the following course:

20. Design a code deployment system#

Problem statement: Design a reliable and scalable code deployment system for a large-scale distributed application. The system should automate building, testing, and rolling out code changes across environments with minimal disruption and the ability to monitor and roll back changes when necessary.

Requirements#

Follow these requirements for a code deployment system:

System Design and workflow#

The high-level design of the code deployment system includes all the major components needed to meet the outlined requirements. The process begins when developers submit code to a version control system (VCS). Any new code changes trigger a continuous integration (CI) service, which automatically integrates updates, runs preliminary tests, and prepares the code for deployment. Once validated, the code is published to a queue, which decouples build triggers from execution.

A dedicated build service listens to this queue and retrieves jobs to compile the code. It then generates binary artifacts and stores them in a versioned blob storage system. These artifacts represent the system’s deployable output. When it’s time to deploy, the deployment service pulls the necessary artifacts from blob storage and installs them on machines across different regions. This ensures consistent deployments in multiple environments, such as staging and production.

The architecture supports gradual rollouts, rollback mechanisms, and monitoring at each step, helping to reduce risks and improve reliability in production.

A high-level design of a code deployment system is depicted in the following illustration:

You can check out the following course for more details on System Design:

21. Design a social media newsfeed service#

Problem statement: Design a scalable and efficient social media newsfeed system that delivers personalized, real-time content updates to users, ensuring low latency, high availability, and scalability.

Requirements#

Follow these requirements for the design:

System Design and workflow#

In the following high-level design of a newsfeed system, clients post or request their newsfeed through the app, which the load balancer redirects to a web server for authentication and routing. Whenever a post is created via the post service and available from a user’s friends (or followers), the notification service informs the newsfeed generation service, which generates newsfeeds from the posts of the user’s friends (followers) and keeps them in the newsfeed cache. Similarly, the generated feeds are published by the newsfeed publishing service to the user’s timeline from the news feed cache. It also appends multimedia content from the blob storage with a news feed if required.

Note: If you need answers to such questions, look at the detailed design of a newsfeed service.

22. Design a collaborative editing service like Google Docs #

Problem statement: Design a collaborative editing service that lets users remotely and simultaneously make changes to text documents. The changes should be displayed in real time. Like other cloud-based services, documents should be consistently available to any logged-in user on any machine. Your solution must be scalable to support thousands of concurrent users.

Requirements#

Follow these requirements for the Google Docs system:

System Design and workflow#

Clients’ requests are forwarded to the operations queue, where conflicts are resolved between different collaborators, and the data is stored in the time series database and blob storage (responsible for storing media files). Autocomplete suggestions are made via the typeahead service. This service resides on the Redis cache to enable low latency suggestions and enhance the speed of the regular updates process. The application servers perform several important tasks, including importing and exporting documents. Application servers also convert documents from one format to another. For example, a .doc or .docx document can be converted into .pdf or vice versa.

Note: If you need answers to such questions, look at the detailed design of Google Docs.

23. Design Google Maps#

Problem statement: Design a service that can map the route between two locations. The system should map several optimal paths to a destination based on the mode of travel. Each route should display the total mileage and an estimated time of arrival.

Requirements#

Follow these requirements for the Google Maps system:

System Design and workflow#

In the Google Maps system, clients request location-based services, such as finding a route or searching for nearby points of interest. The load balancer directs requests to various services based on the nature of the query.
For routing requests, the route finder service calculates optimal paths between two or more points using real-time and historical data. It relies on the graph processing service to perform complex calculations on the road network graph stored in the graph database. The location finder service provides the user’s current location or identifies the location of a specified point of interest. The area search system lets users find nearby places, such as restaurants or gas stations, by querying the graph database and third-party road data sources.

Note: Look at the detailed design of Google Maps to get answers to the questions above.

24. Design a payment gateway like Stripe#

Problem statement: Design a payment gateway like Stripe capable of securely performing online or card transactions and handling millions of users simultaneously.

Requirements#

Follow these requirements for the system:

System Design and workflow#

Initially, a customer selects a product or service via the merchant’s online store and proceeds to the checkout page to provide payment details, including card number, cardholder name, CVV or CVC, and expiration date. Upon clicking the pay button, an event that hits the payment service stores the event, performs initial security checks, and forwards the payment details to the payment service provider for further operations is generated. The payment gateway performs extensive security checks, moves money from the customer’s account to the merchant’s, and provides secondary services like handling refunds and generating invoices. The card network verifies the card information via APIs provided by the card network. Once the payment is processed, the wallet and ledger service updates the merchant’s wallet in the database to track total revenue and processes each order separately in case of multiple sellers. The reconciliation system matches and verifies financial records to ensure accurate transaction accounting, identifying and resolving discrepancies.

You can check out the following course for more details on System Design:

25. Design a food delivery service like Uber Eats or DoorDash#

Problem statement: Design a food delivery service like Uber Eats or DoorDash that efficiently connects hungry customers with diverse restaurants, ensuring timely and accurate order fulfillment while optimizing delivery routes and driver earnings.

Requirements#

Follow these requirements for the DoorDash system:

System Design and workflow#

The following is a level design of DoorDash, consisting of several services for different purposes. Let’s describe the workflow and the interaction of the different services involved in the design.

Customers’ requests are routed through the API gateway and directed to different services via the load balancer. The search service searches for menu items, cuisines, restaurants, etc. It is one of the customers’ busiest services when searching the website or application. The ordering service handles menu selection, managing the shopping cart, and placing food orders. Additionally, it facilitates payment processing through an external payment gateway and stores the outcomes in the relevant database. The order fulfillment service is used to manage the orders that the restaurants have accepted. It also keeps track of orders being prepared.

Customers and restaurant staff use the user management service to create and manage their profiles. The dispatch service displays the orders ready to be picked. It is also used to view delivery information and facilitate communication between customers and restaurant staff.

26. Design a distributed locking service like Google Chubby locking#

Problem statement: Design a highly available, fault-tolerant distributed locking service like Google Chubby to coordinate access to shared resources in a large-scale distributed system.

Requirements#

Follow these requirements for the Google Chubby locking system:

System Design and workflow#

The Chubby cell is composed of multiple servers (usually five), all replicas of each other. One of these servers is a leader with whom the clients must communicate. Each server has a namespace that is composed of directories and files that contain data that is relevant to different applications. In addition to this namespace, the server contains an ACLAccess Control List: A list that tells which processes or people can be given what kind of access to computational resources. files directory to have access control lists of all the files and directories within the namespace. The Chubby library mediates communication between clients and servers in a Chubby cell. It takes a request from a client who wants to use the Chubby service and then finds the relevant cell, directs the request to that cell via remote procedure calls (RPCs), and then reports any changes made in the namespace, data, or metadata (also known as events) back to the client.

Note: Look at the detailed design of Google Chubby locking to get answers to the above questions.

27. Design a coordination system like ZooKeeper#

Problem statement: Design a highly available, fault-tolerant, and scalable coordination system like ZooKeeper to manage configuration, naming, synchronization, and group services in a distributed system.

Requirements#

Follow these requirements for the ZooKeeper system:

System Design and workflow#

The clients are the applications that use ZooKeeper as a coordination service for their application processes. ZooKeeper client library (API) provides functions such as create(), delete(), exists(), and many more to manage and use the coordination data. Through this API, the client request is forwarded to the ZooKeeper server. The ZooKeeper server represents a process that provides the ZooKeeper coordination service. It stores all the coordination data from different applications and their processes in memory. The namespace for applications/clients and their coordination data are organized in a hierarchy (in the form of a tree). The client application processes store their coordination data on znodes. These processes can perform all the operations provided in the ZooKeeper client API. Each znode can be accessed through its path in the standard UNIX notation (like having / for the root directory). There is a set of ZooKeeper servers called ZooKeeper Ensemble. All are replicas. One is elected as the leader, while others become the followers.

Note: If you need answers to such questions, look at the detailed design of ZooKeeper.

28. Design a scalable distributed storage system like Bigtable#

Problem statement: Design a massively scalable distributed storage system like Bigtable capable of handling petabytes of structured and unstructured data with low latency reads and writes, supporting flexible schema, efficient query patterns, and high availability while ensuring data consistency and durability.

Requirements#

Follow these requirements for the Bigtable system:

System Design and workflow#

The following illustration shows that the Bigtable implementation consists of three main parts: a library linked to each client, one Bigtable manager server, and several tablet servers. A library is a component that all clients share. This library enables clients to communicate with Bigtable. The manager server allocates tablets to table servers, identifies tablet server additions and expiration, regulates tablet-server traffic, and garbage collection of files in GFS (a distributed file system). It also supports schema changes like table and column family formation. All tablet servers are in charge of a certain group of tablets, generally around 10 to 1000 tablets. Each tablet server provides reads and writes of the data to the tablets to which it is allocated. Servers can be added or removed in a Bigtable cluster as needed. New tablets can be made and assigned, old ones can be merged, and they can be reassigned from one server to the other to accommodate changes in demand.

Note: If you need answers to such questions, look at the detailed design of BigTable.

29. Design an online multiplayer game system#

Problem statement: Design an online multiplayer game system that allows players to connect and play in real time. The system should handle player matchmaking, maintain low latency communication, ensure player synchronization, and consistently manage game state.

Requirements#

Follow these requirements for such a system:

System Design and workflow#

In an online multiplayer game system, players connect to the game server, which handles matchmaking by pairing players based on skill levels and preferences. Once matched, the server maintains low latency communication between players, ensuring smooth and real-time interactions using a pub/sub service. The game state, including player positions and actions, is synchronized across all players’ devices through a central game state manager. The session service manages sessions and synchronizes the players. The play service will handle all the game-related tasks like updating stats, checking players’ availability, etc. The payment service facilitates in-app purchases of assets.

For a better user experience, we can separate real-time operations, such as gameplay, from non-real-time operations, such as invites and in-app purchases.

Note: To learn more about gaming service design details, explore the gaming API design chapter.

30. Design a Zoom-like video conferencing system#

Problem statement: Design a real-time video conferencing system that supports high-quality meetings with hundreds of participants. The platform should offer interactive features like breakout rooms and polls, work reliably across different network conditions, and scale globally with low latency.

Requirements#

Follow these requirements to design the system:

System Design and workflow#

This high-level design represents a video conferencing service that incorporates several components to provide a seamless experience for users. The system starts with the client, communicating with the API gateway to initiate requests. The API gateway handles authentication and directs the request to the load balancer, efficiently distributing traffic to the appropriate services, such as the user service, scheduling service, meeting service, and messaging service. These services manage user data, scheduling of meetings, real-time communication during meetings, and messaging functionalities. Additionally, the CDN ensures that video and media content is delivered with low latency to users across different geographical regions.

The media router (SFU) plays a critical role in managing media streams in real-time. It handles video and audio streams from multiple participants and forwards them to other participants without modifying the content, ensuring efficient bandwidth usage. The system also integrates a cloud processing service to handle more complex tasks like video processing or analytics. Data is stored in a blob store and a database to keep records of meetings, messages, and user information.

The following illustration shows a high-level design of a video conference service:

Note: Explore the Zoom API design to learn more about designing a video conference service and determine the answers to the above questions.

The final step of your interview prep#

Mastering these 30 questions is a fantastic first step toward comprehensive System Design interview preparation.

However, there are plenty more System Design concepts you’ll need to know for a real-world System Design interview. Educative has created an exhaustive course: Grokking Modern System Design Interview, which includes more detailed questions and answers and the opportunity to get hands-on practice.

This interactive course covers the building blocks of the modern System Design concept, coupled with more than a dozen real-world questions currently used in the industry. By the end of the course, you will understand what clarifying questions to ask and tradeoffs to make for each question. Ultimately, you will learn exactly what it takes to stand out to interviewers in the current hiring market.

That’s why if I had to pick just one System Design prep resource to give you, this would be it.

Quick tips to tackle System Design interview questions#

We all dream of passing the System Design interview with flying colors!

So why not make this dream a reality with some quick tips:

• Practice structured thinking: Always start with a clear outline of your approach. Break problems down systematically, such as:

Requirements ➔ Components ➔ APIs ➔ Data models ➔ Bottlenecks ➔ Trade-offs

• Clarify early, clarify often: Never rush into a design. Spend the first 5-10 minutes asking questions and defining system constraints and assumptions.

• Prioritize communication: Think out loud. Walk your interviewer through your decisions, trade-offs, and reasoning, even if unsure.

• Use diagrams: Visual aids like high-level architecture diagrams make your solution much easier to understand and show that you think like a true architect.

• Review actual systems: Study the architectures of popular platforms like Instagram, Uber, Netflix, and Dropbox to understand real-world trade-offs.

• Stay calm under pressure: Keep moving forward even if you get stuck. Composure, problem-solving attitude, and logical thought are often more important than reaching a “complete” design.

I wish you the best of luck with your interviews. I am confident that with a little hard work and strategic preparation, you will be successful.

Happy learning!

Related courses#

The following are some relevant courses that will help you to further your learning in the System Design and distributed systems domain:
