Overview#
You will probably have heard all the buzz about machine learning and its applications. And if you have, you’ve probably heard about
Classification problems: The
-NN algorithm can be used in pattern recognition and other classification problems, such as identification of spam emails and classification of documents. Recommender systems: The
-NN algorithm can be applied to find similar users or items and make recommendations. Regression analysis: The
-NN algorithm can also be used for regression tasks, such as predicting housing prices based on features such as area, location, and number of bedrooms. Healthcare and medicine: The
-NN algorithm can assist in identifying the likelihood of certain diseases based on patient data and historical records.
In this blog, our focus will be on only classification problems. We’ll take a look at a numerical example running the
Now, let’s explore the basics of the
Introduction to kkk-NN#
What is
How kkk-NN works#
Let’s take a look at the
Step 1: To classify a test instance
How to define the value of :
The value is usually an odd number to avoid a 50% split in a binary classification problem. A low value of is more error-prone (or might not give accurate results). In practice, the value of is usually set to be aroundsqrt(n), wherenis the number of instances in the dataset.
Step 2: Calculate the similarity (often using Euclidean distance or other distance metrics) between the new item and all data points in the training dataset. Based on the similarity values, extract
Step 3: Assuming multiple classes (
Step 4: Assign
Example#
Assume that we have the following dataset:
Data point | Class |
(2, 3) | A |
(3, 4) | A |
(5, 6) | B |
(7, 8) | B |
(1, 2) | A |
(6, 7) | B |
(4, 5) | A |
(8, 9) | B |
(2, 2) | A |
(9, 9) | B |
We also have the following test data point: (6, 5)
Step 1: To classify a test instance (6, 5), define the
As mentioned above, the value of is usually set to sqrt(n), where n is the number of training instances. In our example dataset, n is 10, therefore is set to 3.
Step 2: We calculate the similarity between the new instance and all data points in the training dataset.
Note: We’ll be using the Euclidean distance formula in our calculations.
Recall the formula for Euclidean distance:
Here,
After calculating distances, here is a table of distances from each point to our test point, i.e., (6, 5):
Data point | Distance from (6, 5) |
(2, 3) | 4.47 |
(3, 4) | 3.16 |
(5, 6) | 1.41 |
(7, 8) | 3.16 |
(1, 2) | 5.83 |
(6, 7) | 2 |
(4, 5) | 2 |
(8, 9) | 4.47 |
(2, 2) | 5 |
(9, 9) | 5 |
Step 3: Count the number
Data point | Class | Distance from (6, 5) | Rank |
(2, 3) | A | 4.47 | |
(3, 4) | A | 3.16 | |
(5, 6) | B | 1.41 | 1 |
(7, 8) | B | 3.16 | |
(1, 2) | A | 5.83 | |
(6, 7) | B | 2 | 2 |
(4, 5) | A | 2 | 3 |
(8, 9) | B | 4.47 | |
(2, 2) | A | 5 | |
(9, 9) | B | 5 |
Step 4: Assign the test instance (6, 5) the class that’s the most frequent or the majority class.
From the above table, we can see that in neighborhood of the point (6, 5), two of the closest instances belong to class , whereas one instance belongs to class . Therefore, the test instance (6, 5) is assigned class .
kkk-NN algorithm in Python#
The following code implements the math library) in this implementation example.
import math# Sample datasetdata = [(2, 3, 'A'), (3, 4, 'A'), (5, 6, 'B'), (7, 8, 'B'), (1, 2, 'A'), (6, 7, 'B'), (4, 5, 'A'), (8, 9, 'B'), (2, 2, 'A'), (9, 9, 'B')]# Function to calculate Euclidean distance between two pointsdef euclidean_distance(point1, point2):distance = 0distance = math.sqrt((point1[0] - point2[0])**2 + (point1[1] - point2[1])**2)return distance# k-NN algorithmdef k_nearest_neighbors(data, query_point, k):distances = []# Calculate distances from the query point to all data pointsfor data_point in data:distance = euclidean_distance(query_point, data_point)distances.append((data_point, distance))# Sort distances in ascending orderdistances.sort(key=lambda x: x[1])# Get the k-nearest neighborsneighbors = [item[0] for item in distances[:k]]# Count the occurrences of each class among the neighborsclass_counts = {}for neighbor in neighbors:label = neighbor[2]if label in class_counts:class_counts[label] += 1else:class_counts[label] = 1# Determine the majority classsorted_class_counts = sorted(class_counts.items(), key=lambda x: x[1], reverse=True)return sorted_class_counts[0][0]# Test the k-NN algorithmquery = (6,5)k = 3result = k_nearest_neighbors(data, query, k)print(f"The query point {query} belongs to class: {result}")
The code is explained below:
Line 1: We start by importing the math library, which is later used to calculate square roots while computing Euclidean distances between two points.
Lines 7–11: We define the euclidean_distance function between two points.
Line 14: We start defining the k_nearest_neighbors algorithm, which takes three arguments: data (the dataset), query_point (the point for which we want to find k (the number of neighbors).
Line 15: We initialize an empty list called distances to store distances between query_point and the data points.
Lines 18–20: We initialize a loop to iterate through each data point in the dataset. We then call the euclidean_distance function that calculates the distance between query_point and the current data_point and store it in the distance variable. Finally, we append a tuple containing the data point and its distance to the distances list.
Line 23: We then sort the distances list in ascending order based on the distances. This step identifies the
Line 26: Next, we select the distances list and store them in the neighbors list.
Lines 29–35: We start by initializing an empty dictionary called class_counts to count the occurrences of each class among the neighbors. Then, we initiate a loop to iterate through each neighbor in the neighbors list. We store the class label (label. We then have an if-else condition. We first check if the class label already exists. If it does, we increment its count by 1. Otherwise, we add it to our dictionary with a count of 1.
Lines 38–39: We now need to determine the majority class. For this, we sort the class_counts dictionary items in descending order, followed by returning the class label with the highest count (majority class).
Lines 42–45: Now, we need to test our query_point to be (6, 5) and set the value of k to be 3. We then call the k_nearest_neighbors function and print the result.
Advantages and disadvantages of using the kkk-NN classification algorithm#
Let’s now take a look at a few advantages and disadvantages of using
Advantages
The algorithm is simple to understand and implement.
Unlike other classification algorithms, there’s no training involved. Learning is instance-based.
The algorithm can adapt to changing data, also known as lazy learning.
No assumptions are made about data distribution.
The models generated by
-NN are interpretable. We can easily visualize decision boundaries.
Disadvantages
The algorithm can be computationally expensive with large datasets.
-NN is sensitive to the choice of . The algorithm has limited ability to capture complex relationships.
The
-NN algorithm might suffer from the curse of dimensionality. This curse refers to the phenomenon where the performance of algorithms such as -NN degrades as the number of features or dimensions in the dataset increases. Scalability can be an issue with large datasets.
Conclusion and next steps#
This blog has provided a thorough answer to what is the -NN algorithm. We mentioned some use-cases, along with advantages and disadvantages of using the -NN algorithm for classification. We also demonstrated our example with code without using any Pyhton libraries.
